Technical Drawing

Technical Drawing

Technical drawing (also known as drafting or engineering drawing) is a precise and detailed form of drawing used to visually communicate how something functions or is constructed. It is commonly used in architecture, engineering, manufacturing, and design.

Here’s a breakdown of key terminology in technical drawing, especially related to geometric drawing:


🔹 Basic Geometric Drawing Terms (English)

TermDefinition
PointAn exact location in space with no dimensions.
LineA straight one-dimensional figure extending infinitely in both directions.
Line SegmentA part of a line between two endpoints.
RayA line that starts at a point and extends infinitely in one direction.
AngleFormed by two rays (or lines) with a common endpoint (vertex).
VertexThe common endpoint of two or more rays or lines forming an angle.
PlaneA flat, two-dimensional surface that extends infinitely.
CircleA set of points equidistant from a central point.
ArcA portion of the circumference of a circle.
RadiusA line from the center of a circle to any point on its circumference.
DiameterA line passing through the center, connecting two points on the circle.
ChordA line segment connecting two points on a circle, not necessarily through the center.
PolygonA closed figure formed by a finite number of straight line segments.
Triangle, Square, Hexagon, etc.Types of polygons, named by the number of sides.
Parallel LinesLines in the same plane that never intersect.
Perpendicular LinesLines that intersect at a 90° angle.
TangentA line that touches a curve or circle at exactly one point.

🔹 Technical Drawing-Specific Terms

TermDefinition
Orthographic ProjectionA method of representing 3D objects in 2D using front, top, and side views.
Isometric DrawingA 3D representation where axes are equally spaced at 120°.
Section ViewA view showing the interior of an object as if it were cut.
DimensioningAdding measurements to a drawing.
ScaleThe ratio between the drawing size and actual size.
Hatching (or Crosshatching)Patterns used to indicate material or cut surfaces in section views.
Title BlockContains information about the drawing (e.g., title, scale, date, drafter).
ToleranceThe permissible limit of variation in a dimension.
Hidden LineA dashed line representing edges not directly visible.
Center LineA line representing the center of a circle or symmetrical object.
Leader LineA line that connects a note to a feature on the drawing.
